Mining Bucket Elevator

Bucket Elevator

Bucket elevators are used in various industries, such as coal mining, construction, cement industry, and mineral processing to lift materials such as coal, cement, bricks, sand, clay, and ore. The bucket elevator is suitable for lifting high-temperature materials and has a special circular chain structure.

The bucket elevator consists of an active pulley, an elevator shoe (lower section) with a tensioning pulley, an elevator housing, a driving device, a rear gear, and a braking device.

Parameters

Model	Hopper type	Conveyor Capacity (m³/h)	Bucket width (mm)	Bucket capacity (L)	Pitch of buckets (mm)	Band width (mm)	Bucket speed (m/s)	The maximum size of material (mm)
TD160	Q	9	160	0.5	280	280	1.4	25
	H	16		0.9
	zd	16		1.2	350
	sd	27		1.9
TD250	Q	20	250	1.12	360	350	1.6	35
	H	36		2.24
